Multi-Modal Vision-Language Model for Cancer Diagnosis
Cross-modal pipeline correlating high-dimensional medical imaging with unstructured biomedical literature, with a Grad-CAM + Gradio explainability interface for clinical interpretability.
Pipeline
The problem
Tumour assessment reads imaging and clinical narrative separately, and single-modality deep models return a label without showing which region of the scan drove it — which clinicians cannot act on.
Architecture
End-to-end flow, stage by stage.
- 01
MRI imaging
- 02
Vision Transformer
- 03
BioBERT fusion
- 04
Grad-CAM
- 05
Gradio UI
How it works
Single-modality baselines first
Separate notebooks establish reference points: BioBERT and ClinicalBERT on the clinical report corpus, and a Vision Transformer on the MRI images, so cross-modal gains can be attributed rather than assumed.
Cross-modal fusion
Image features and clinical text representations — including synthetic text experiments — are combined in a cross-modal training notebook, with dedicated inference and evaluation notebooks reporting accuracy, F1 and AUROC on cleaned train/validation splits.
Explainability in the loop
Grad-CAM heatmaps are surfaced through a Gradio interface so a reviewer can see the image regions behind each prediction instead of trusting a bare score, reaching 80% validation accuracy on the MRI tumour task.
Reproducible data contract
Raw and cleaned CSVs are kept side by side with an explicit input/output contract, so notebook runs are repeatable and the pipeline extends to other cancer types, modalities and text sources.
- Fused Vision Transformer features from MRI scans with BioBERT and Clinical BERT representations of clinical text to support cross-modal diagnostic reasoning.
- Reached 80% validation accuracy on MRI tumor data and exposed Grad-CAM heatmaps through a Gradio interface so clinicians could inspect the image regions influencing each prediction.
- Designed the inference pipeline to extend across additional cancer types, imaging modalities, and biomedical text sources rather than remain tied to one dataset.
By the numbers
From text-only to explainable cross-modal
Validation accuracy (%)
higher is betterModalities used
higher is betterModel families benchmarked
What it ships with
- BioBERT and ClinicalBERT text baselines
- Vision Transformer imaging baseline
- Cross-modal training and inference notebooks
- Grad-CAM explainability via Gradio
- Cleaned, versioned train/validation metadata
- Text-only reports→80%
- Validation accuracy on MRI data
- Black-box→Grad-CAM
- Per-prediction explainability
